navDESCRIPTIOn
The NEW linear stage LMS-60 was designed for industrial applications with high speed requirements within and limited space conditions. Linear stages LMS-60 are driven by linear motors and are equipped with a linear scale. learn more...
The very small height of 14 mm allows very compact setups. All Linear Stages of the LMS-60 series are equipped with limit switches for protection against damage.

navDefinitions
New Product New Product
  Linear or Rotation Feedback Linear or Rotation
Feedback
  Linear Motor Linear Motor

Linear Motor Stage LMS-60 Load Symbol
navKey features
 navLinear Motor
 navTravel range up to 65 mm (LM-054)
 navUni-directional repeatability down to 0.1 µm
 navMaximum speed 500 mm/sec
 navLoad capacity up to 3 kg
 navIntegrated limit switches
 navIntegrated linear scale

navFacts
Load
Characteristics
 Fx
(N)		 Fy
(N)		 Fy
Peak (N)		 Fz
(N)		 Mx
(Nm)		 My
(Nm)		 Mz
(Nm)		 kax
(µrad/Nm)		 kay
(µrad/Nm)
LM-051 25 7 31 30 4 4 10 on request on request
LM-054 25 7 31 30 4 4 10 on request on request
navTECHNICAL DATA
Travel range (mm)
 25 65
Straightness / Flatness (µm) ± 1 ± 2
Pitch (µrad) ± 80 ± 100
Yaw (µrad) ± 80 ± 100
Weight (kg) 1 1.8

Motor LM-051 LM-054
Linear scale     LS-070
Speed max. (mm/sec) 500 500
Resolution calculated (µm)     0. 015
Resolution typical (µm)     0.1
Bi-directional Repeatability (µm)     ± 0.1
Uni-directional Repeatability (µm)     0.1
Nominal Current (A) 0.32 0.64
Accuracy on request
Velocity Range (mm/sec) 0.001 ... 100
Material Steel
navNote:
navMore info:
FS = full step, RE = rotary encoder
Detailed info, concerning the motors and encoders, see: Appendix...

  • DRAWING INFO


  • ORDERING INFO & DETAILS ON REQUEST


Travel range (mm) 25 65
A (mm) 75 60
B (mm) - 120
C (mm) 145 185
D (mm) 68.5 88.5

drawing info
Please fill in all fields marked with *
Order no.: * 6841-9-


Travel range (Motor):
 25 mm (LM-051)   1
65 mm (LM-054)   2
Encoder: LS-070, Linear steel scale   1
Switches: HLS-020, Hall limit switches   1
Salutation ..................
Name .........................
Company / Institut ....
Country *.....................

Download ..................
Your message ..........
How did you find us
Application / Markets
By submitting your E-Mail, you agree to allow your data to be stored for the legally permissible purposes. Data privacy note...

Please fill in all fields marked with *

navAll Product Innovations in 2011 can be found here.
navDownload the complete MAC PhotonX 2007 catalog 10MB
navDownload the complete MOTION CONTROL VOL10 catalog 15MB
